Quickly swap your biological media or chemical solutions
Save time thanks to sequence programming
Switch between up to 12 liquids
Inject 1 sample into 12 outputs or 12 samples into 1 output
Perform microfluidic sequential injection with the 12/1 Rotary Selector Bidirectional Valve.
Combined with the OB1 MK4 pressure controller, the MUX Distribution valve will allow you to automate injection in microfluidic experiments, program perfusion experiments, sequentially supply different reagents and many more applications.
Several solutions from one outlet or one feed directed into different outlets.
Use the MUX Distribution valve to sequentially inject up 12 different solutions into one microfluidic line for sample collections or parallel experiments.
Bidirectional 13 ports/ 12 positions sequential injection from 12 different samples into 1 output/input
The MUX Distrib’ 12/1 can be used in various fields of application and for any experiment that requires successive injection of fluids: from organic synthesis, flow chemistry, drug screening, biochemical and electrochemical sensor calibration, calibration (bench testing), sensors test rig, toxicity test, Seq-Fish experiment…
For more biology-related content, please refer to the cell perfusion application pack.
Adaptable pulsatile flow generated from stem cell-derived cardiomyocytes using quantitative imaging-based signal transduction
T. Qian et al., Lab on a Chip, 2020, 20, 3744-3756, DOI: 10.1039/D0LC00546K
Microfluidic platform for 3D cell culture with live imaging and clone retrieval
C. Mulas et al., Lab on a chip, 2020, 20, 2580-2591, DOI: 10.1039/D0LC00165A
Microfluidic Control of Nucleation and Growth of CaCO3
D. K. Dysthe et al. Cryst. Growth Des. 2018, 18, 8, 4528–4535
| MUX DISTRIBUTION VALVE SPECIFICATIONS | |
|---|---|
| FLUIDIC SPECIFICATIONS | |
| Valve type | 12 positions / 13 ports rotative valve |
| Fluidic connectors | Standard 1/4-28 UNF, flat-bottom |
| Internal volume | 3.5 µL |
| Dead volume(1) | None |
| Internal diameter | 0.5 mm |
| Wetted materials | PCTFE and PTFE |
| Max supported pressure | 7 bar |
| CONTROL & MONITORING | |
| Maximum valve update rate | 2 Hz |
| Software control | Elveflow Smart Interface – Windows 10, 11, both 32 and 64 bit versions supported |
| Software Development Kit | Libraries available: Matlab, Python, LabView, C++ – Windows 10, 11, both 32 & 64 bit versions supported Serial/UART communication protocol on request |
| Data management | Possibility to log and extract data (CSV), channel and sensor detailed information using ESI |
| Automation | Generate step-by-step sequences using the ESI built-in sequence management Log and export custom configurations (CSV) |
| ELECTRICAL SPECIFICATIONS | |
| Voltage | 24 V |
| Maximum power consumption | 36 W |
| Power connection | DC power connector, Plug, 3A, 2.1mm, 12mm |
| Interface | USB Type B |
| Communication Type | Serial |
| Supply Voltage Range (V) | 100 to 240 VAC |
| Supply AC Frequency (Hz) | 50 to 60 Hz |
| Maximum Output Current (A) | 1.67 A |
| Maximum Output Power (W) | 40 W |
| MECHANICAL SPECIFICATIONS | |
| Dimensions (length x width x height) | 157 x 126.5 x 134 mm |
| Operating temperature | 5°C to 40°C |
| Operating humidity | 20-70% non condensing |
